100kWh 512V 205Ah
HV Commercial Solar Battery Storage
ESS-GRID S205 is the standard 100kWh - 167kWh HV commercial solar battery solution of BSLBATT for microgrid, community electricity, which can meet various scenarios such as community power generation, off-grid devices on isolated islands, and farms using solar power. It adopts safe and reliable LiFePO4 battery with 512V -819.2V and 205Ah capacity, and is compatible with high-voltage three-phase inverters and commercial and industrial PCS.
Exploring the Latest Product in Commercial Solar Battery Storage
BSLBATT ESS-GRID Station series offers a cutting-edge commercial and industrial energy storage system designed to meet the needs of high-power applications.
Our system features a 105kWh/115kWh/126kWh/136kWh/146kWh/157kWh/167kWh battery capacity and is specifically engineered to deliver reliable, long-lasting power to industrial and commercial operations.
The system is designed to maximize efficiency and minimize costs, with advanced software algorithms that optimize battery usage and ensure optimal performance. Our energy storage system is built with the latest technology and materials, providing a safe and durable solution that is easy to install and maintain.
Our team of experts is dedicated to ensuring that each customer receives a customized energy storage solution that meets their unique requirements and delivers the highest level of performance and reliability.
Feature Description
Max. Parallel Connection of 10 Groups
Max. Capacity 1.6MWh
| ESS-GRID | S205-10 | S205-11 | S205-12 | S205-13 | S205-14 | S205-15 | S205-16 |
| Rated Voltage(V) | 512 | 563.2 | 614.4 | 665.6 | 716.8 | 768 | 819.2 |
| Rated Capacity(Ah) | 205 | ||||||
| Cell Model | LFP-3.2V 205Ah | ||||||
| System Configuration | 160S1P | 176S1P | 192S1P | 208S1P | 224S1P | 240S1P | 256S1P |
| Rate Power(kWh) | 105 | 115.5 | 126 | 136.4 | 146.9 | 157.4 | 167.9 |
| Charge Upper Voltage(V) | 568 | 624.8 | 681.6 | 738.4 | 795.2 | 852 | 908.8 |
| Discharge Lower Voltage(V) | 456 | 501.6 | 547.2 | 592.8 | 638.4 | 684 | 729.6 |
| Recommended Current(A) | 102.5 | ||||||
| Max. Charging Current(A) | 200 | ||||||
| Dimension(L*W*H)(MM) | High Voltage Control Box | 501*715*250 | |||||
| Single Battery Pack | 501*721*250 | ||||||
| Number of Series | 10 | 11 | 12 | 13 | 14 | 15 | 16 |
| Communication Protocol | CAN BUS / Modbus RTU | ||||||
| Host Software Protocol | CANBUS (Baud rate @500Kb/s or 250Kb/s) | ||||||
| Operation Temperature Range | Charge:0~55℃ | ||||||
| Discharge: -20~55℃ | |||||||
| Cycle Life(25°C) | ＞6000 @80%DOD | ||||||
| Protection Level | IP20 | ||||||
| Storage Temperature | -10°C~40°C | ||||||
| Storage Humidity | 10%RH ~90%RH | ||||||
| Internal Impedance | ≤1Ω | ||||||
| Warranty | 10 years | ||||||
| Battery Life | ≥15 years | ||||||
| Weights(KG) | 907 | 992 | 1093 | 1178 | 1263 | 1348 | 1433 |
