Product Description
Multiple Capacity Lithium Battery Wall Mount Options
Item | General Parameter | ||||||
Nominal Voltage | 51.2V | ||||||
Cell Model(LFP-3.2V) | 100Ah | 67Ah | 52Ah | 86Ah | 100Ah | 280Ah | 100Ah |
Pack configuration | 16S1P | 16S2P | 16S3P | 16S2P | 16S2P | 16S1P | 16S3P |
Rate power(Wh) | 5120 | 6861 | 7987 | 8806 | 10240 | 14336 | 15360 |
Charging Voltage | 58.4V | ||||||
Float charge Voltage | 55V | ||||||
Discharge Cut-off Voltage | 40V | ||||||
Charging Current limits | 80A | 120A | 160A | ||||
Max Discharging current | 100A | 150A | 200A | ||||
Charge over Current protect | 110A | 160A | 210A | ||||
Discharge over Current protect | 115A | 165A | 215A | ||||
Pack Weight | 53kg | 62kg | 71kg | 78kg | 95kg | 110kg | 130kg |
Internal Impedance | ≤100mΩ | ||||||
Communication protocol | CAN(500Kb/s)/RS485(9600b/S) | ||||||
Host software and Communication protocol | RS232 | ||||||
Operation Temperature Range | Charge:0~55℃ | ||||||
Discharge: -10~55℃ | |||||||
Storage Temperature Range(recommend) | 0℃~25℃ |
