The home photovoltaic systems power generation project is guaranteed by the grid company for grid-connected consumption. So how feasible is it to equip the home photovoltaic systems project with a home power bank? How many years can the cost be recovered? And what is the current global usage situation?
In this article, we will discuss the feasibility analysis of the current photovoltaic solar system configuration home power from three cases.
In some developed areas, the cost of electricity consumption is relatively high, and the overall grid facilities are not stable and reliable. Therefore, reducing the comprehensive electricity cost is the main driving force for installing home power.
From the perspective of per capita electricity consumption, the per capita electricity consumption of Germany/USA/Japan/Australia will be 7,035/12,994/7,820/10,071 kWh respectively in 2021, which is 1.8/3.3/1.99/2.56 times of China's per capita electricity consumption (3,927kWh) in the same period.
From the perspective of electricity prices, residential electricity prices in developed regions around the world are also significantly higher. According to statistics from Global Petrol Prices, the average residential electricity price in Germany/United States/Japan/Australia in June 2020 is 36/14/26/34 cents/kWh, which is 4.2/1.65/3.1/4 times of China's residential electricity price (8.5 cents) in the same period.
Case 1：Australia Residential solar home power systems
Australia's average electricity bill has many variables, depending on the size of your home and the number of appliances you use every day. However, the average national electricity consumption in Australia is 9,044 kWh per year or 14 kWh per day. Unfortunately, in the past three years, household electricity bills have risen by more than $550.
The household electrical equipment and power are shown in the following table:
| Serial Number | Electrical Equipment | Quantity | Power（W） | Electricity Time | Total Electricity Consumption（Wh) |
| 1 | illumination | 3 | 40 | 6 | 720 |
| 2 | Air conditioner (1.5P) | 2 | 1100 | 10 | 1100*10*0.8=17600 |
| 3 | refrigerator | 1 | 100 | 24 | 24*100*0.5=1200 |
| 4 | TV set | 1 | 150 | 4 | 600 |
| 5 | Micro-wave oven | 1 | 800 | 1 | 800 |
| 6 | washing machine | 1 | 230 | 1 | 230 |
| 7 | Other equipment (computer / router / range hood) | 660 | |||
| Total Power | 21810 | ||||
The average monthly electricity consumption of this household in Australia is about 650 kWh, and the average annual electricity consumption is 7,800 kWh per month. According to the electricity price trend report of the Australian Energy Market Council, Australia's average annual electricity bill this year has increased by $100 over the previous year, reaching $1,776, and the average electricity bill per kilowatt-hour is 34.41 cents:
Calculated with 7,800 kilowatt-hours of electricity per year: Annual electricity bill=$0.3441*7800kWh=$2683.98
Off The Grid Home Power Systems Solution
According to the situation of the house, we designed a single-phase Solar power battery solution. The design uses 12 500W modules, a total of 6kW modules, and installs 5kW bidirectional energy storage inverters, which can generate 580~600kWh of electricity per month on average. Photovoltaic power can be used part of the time, and BSLBATT 7.5kWh lithium battery energy storage is configured according to the 6-hour peak power consumption period, which is used for load power consumption during peak periods without sunlight. Solar home power as a whole can basically meet customer demand for electricity.
Economic benefit analysis: At present, the cost of photovoltaic systems is $0.6519/W, and the cost of low-voltage energy storage batteries is about $0.2794/Wh. The energy storage investment of 5kW + BSLBATT 7.5kWh Powerwall battery is about $6000, and the main costs are as follows:
| Serial Number | Equipment Name | Specification | Quantity | Total Price (USD) |
| 1 | Solar Power Kits | Crystalline silicon 50Wp | 12 | 1678.95 |
| 2 | Energy Storage Inverter | 5kW | 1 | 1399 |
| 3 | Powerwall Battery | 48V 50Ah LiFeP04 battery | 3 | 2098.68 |
| 4 | Other | / | / | 824 |
| 5 | Total | 6000.63 | ||
Case 2: America self-operated cake shop users
Its electrical equipment and power are shown in the following table:
| Serial Number | Electrical Equipment | Quantity | Power（W） | Electricity Time | Total Electricity Consumption（Wh) |
| 1 | illumination | 3 | 50 | 10 | 1500 |
| 2 | Air conditioner (1.5P) | 1 | 1100 | 10 | 1100*10*0.8=8800 |
| 3 | Cold room | 2 | 300 | 24 | 24*600*0.6=8640 |
| 4 | refrigerator | 1 | 100 | 24 | 24*100*0.5=1200 |
| 5 | oven | 1 | 3000 | 8 | 24000 |
| 6 | Bread machine | 1 | 1500 | 8 | 12000 |
| 7 | Other Equipment (mixer / beater) | 960 | |||
| Total Power | 57100 | ||||
The store is located in Texas, with an average monthly power consumption of about 1400 kWh. The commercial electricity price in this place is 7.56 cents/kWh:
According to calculations, the monthly electricity bill of the changed merchant=$0.0765*1400kWh=$105.84
Off The Grid Home Power Systems Solution
According to the user's situation, the system adopts a three-phase residential battery solution. The system is designed to use 24 500W modules, a total of 12kW modules, and a 10kW two-way energy storage inverter, which can generate 1,200 kilowatt-hours of electricity per month on average, which basically meets the customer's electricity needs. According to the operation of the cake shop, most of the load is concentrated in the peak power consumption period during the day, and the load is small at night. Therefore, photovoltaic power can be mainly used during the peak power consumption period, supplemented by home battery for solar and the grid; it can be mainly used at night solar power battery backup power, grid power as a supplement; therefore, home energy storage is equipped with BSLBATT 15kWh lithium battery.
10kW photovoltaic solar system + BSLBATT 15kWh solar ac battery investment is about $12122, the main costs are as follows:
| Serial Number | Equipment Name | Specification | Quantity | Total Price (USD) |
| 1 | Solar Power Kits | Crystalline silicon 500Wp | 2 | 3358 |
| 2 | Energy Storage Inverter | 10kW | 1 | 1700 |
| 3 | Powerwall Battery | 336V 50Ah LiFeP04 battery | 1 | 6007 |
| 4 | Other | / | / | 1057 |
| 5 | Total | 12122 | ||
Economic benefit analysis: Photovoltaic can basically meet the electricity demand. With the addition of photovoltaic battery, electricity can be used more securely, even if the grid is out of power, it can save users 1061.7 yuan in electricity bills every month, and the annual electricity bill is about 12,700. Therefore, The cost can be recovered in about 6 years, the life of the photovoltaic module is 25 years, and the life of the photovoltaic battery system is 10 years, so the system has a high investment value.
Case 3: German Residential Battery
Take Saxony in Germany as an example. The region encourages household photovoltaics and the feed-in limit of the grid feed point is 50%. Homeowners are encouraged to use photovoltaic battery backup to increase the spontaneous self-use rate; for residential solar Home power systems provide 1,000 euros + 200 euros/kWh (at least 2kWh installed), and can subsidize up to 4,000 euros (1 euro = 1.17 US dollars), and there is no installation period limit.
The current cost of power home solutions in the German solar market is about 380$/kW for photovoltaics and 590$/kWh for batteries; therefore, a 5kW+7.5kWh solar photovoltaic battery system adopts the same configuration, and the total cost is: 2188.8+4425=6613.8 US dollars; subsidies The post-system cost is 3688.8 US dollars; the average annual electricity bill for a family of 3 in Germany is at least 1065 US dollars, so the cost can be recovered in about 3.6 years.
Photovoltaic Solar System+Solar Power Battery Storage Will Eventually Become Mainstream Energy
The continuous reduction in the cost of lithium batteries and the strong support of various policies for the home power system business, as well as the high spontaneous self-utilization rate of the home power system itself, peak shaving and valley filling, and enhancement of the stability of the new energy power system, make the photovoltaic battery storage system in the field of new energy, there is a torrent of courageous progress.
Fully subvert the traditional energy demand and realize that the comprehensive cost of photovoltaic battery storage system is lower than that of thermal power. This is the reason why photovoltaic battery storage system will eventually become mainstream energy. It is not necessarily because it is the cleanest, but it must be because it is the cheapest. The system cost of home photovoltaic systems has been reduced to $0.47/W. I think the system cost reached $9.31/W in 2007. In 13 years, the cost has dropped to only 5% of the original cost; lithium batteries for solar power storage has dropped to $0.23/wh, the number of charging and discharging can reach 5000 times.
In 2025, the cost of alternative power sources for home will be $0.34/W, and it will be depreciated for 25 years plus financial costs, 1500 hours/year of power generation hours, and the cost of electricity is $0.16 per kilowatt-hour; solar power batteries cost $0.16/Wh, charging The number of releases is 10,000 times, depreciated for 15 years. The storage cost per kilowatt-hour is 0.1 yuan per kilowatt-hour, and the financial cost is $0.02 per kilowatt-hour; the cost of photovoltaic battery storage system is $0.036/kw, and the cost is expected to drop to $0.023 per kilowatt-hour in 2030 Within, sweep all fossil energy.
It is a high probability event that photovoltaic battery storage system can occupy 20% of the global power market in 2030, about 9 trillion kilowatt-hours of electricity. According to global power generation conditions, the average annual photovoltaic power generation capacity of 1250 hours can be expected, 1GW (1 million KW) installed capacity is about 1.25 billion kWh and 9 trillion kWh. The total installed capacity is 7,200GW, and the ground installation area is about 70,000 square kilometers. The cost of photovoltaic ground system is predicted to be $0.34/W in 2025 (module $0.16/W) and $0.28/W in 2030 (module $0.13/W). As of the end of 2020, the total global installed capacity of photovoltaics is about 750GW, and 6450GW photovoltaic battery storage system will be added in the next 10 years. The huge space is enough to make people excited.
With more energy storage policy incentives, market system improvement, and technological progress brought about by the cost reduction of energy storage systems, the deployment of home power for domestic home photovoltaic projects will become the norm for new energy sources.
